30W UKCA Certified Wall Power Adapter
Professional 30W UKCA certified wall power adapter designed for reliable performance across various electronic applications.
Technical Specifications
Output Mode: Constant voltage
Input Voltage: AC100-240Vac, 50/60Hz or 220-240Vac, 50/60Hz
Output Range: DC5V-36V, 0.01A-4A, 48W Max
Protections: Short circuit, over current, over voltage
Energy Efficiency: DOE, CEC, ERPII MEPS GEMS
Operating Environment: 0-40℃, 5%-95% RH
Certifications: UL, cUL, FCC, GS, CCC, CQC, KC, PSE, UKCA, SAA, C-tick, RCM, RoHS, CB
Regional Specifications
| Country |
Max. Watt |
Voltage Range |
Current Range |
Safety Standard |
| US |
48W |
DC5-36V |
0.01A-4.0A |
EN62368/UL 1310 |
| EU |
48W |
DC5-36V |
0.01A-4.0A |
EN62368 |
| UK |
48W |
DC5-36V |
0.01A-4.0A |
EN62368 |
| AU |
48W |
DC5-36V |
0.01A-4.0A |
EN62368 |
| KR |
48W |
DC5-36V |
0.01A-4.0A |
EN62368 |
| JP |
48W |
DC5-36V |
0.01A-4.0A |
EN62368 |
| CN |
48W |
DC5-36V |
0.01A-4.0A |
CCC-GB 4943.1-2022/CQC-GB 4343.1-2018;GB/T 4343.2-2020 |
Key Features
- Single channel constant voltage power supply
- 100% full load burn-in testing
- Passes LPS (limited power source) requirements
- 3-year comprehensive warranty
- Class II power design (without earth pin)
- Compact size with fully enclosed PC plastic case
- Fast startup time: <3 seconds
- High energy efficiency: DOE/CEC/ErP/MEPS/NRcan Level VI
- Automatic safety protections for over current, over load, and short circuit
FQA
Q1: What certifications does this 30W wall power adapter have?
A: It holds UKCA, UL, cUL, FCC, GS, CCC, CQC, KC, PSE, SAA, RCM, RoHS, CB and other global certificates, complying with regional safety standards.
Q2: What is the output specification? Can I get different DC voltages?
A: Constant‑voltage single‑channel, DC 5‑36V, max 48W. Multiple DC connectors are available, custom options are supported.
Q3: What safety protections are included?
A: Short‑circuit, over‑current, over‑voltage & overload protection. Passes LPS limited power source requirements. 100% full‑load burn‑in tested.
Q4: Which plugs and DC connectors are available?
A: AC plugs for US/EU/UK/AU/KR/JP/CN/BR/IN/AR etc. Common DC tips:5.52.1,5.52.5,4.01.7,3.51.35,2.5*0.7,XLR, custom connectors acceptable.
Q5: What environments and applications is it for?
A: Indoor‑use only, non‑waterproof. Operating temp:0‑40℃, RH 5‑95%. Suitable for LED strips, amplifiers, routers, audio‑video devices and other electronics.
Q6: Can you do OEM & ODM?
A: Yes. Custom labels, packaging, housing and connectors are available.
Q7: What is your warranty term?
A: 3‑year comprehensive warranty.
Q8: Is this adapter Class I or Class II?
A: Class II design, no earth pin required.
Why choose us?
Full‑certified 30W wall adapter
Comprehensive global certifications including UKCA, UL, FCC, CCC, KC, PSE, SAA, RCM and RoHS, compliant with safety standards for US, EU, UK, AU, JP, KR, CN markets.
Wide voltage & strong compatibility
Single‑channel constant‑voltage design, DC 5‑36V wide output range, supports multiple AC plugs and DC connectors, fits LED strips, amplifiers, routers and other indoor electronics.
Complete safety protection
Built‑in over‑voltage, over‑current, short‑circuit protection, meets LPS limited power source requirements. 100% full‑load burn‑in test ensures stable performance. Class II double‑insulation design, no earth pin needed.
High‑efficiency energy‑saving performance
Meets DOE VI, CEC, ErP II, MEPS energy‑efficiency standards, fast startup＜3s, compact enclosed PC housing for indoor use.
Reliable warranty & flexible customization
3‑year full warranty. Support OEM / ODM: custom labels, packaging, housing and connector options for your project.
Compatible AC Plugs
US, EU, UK, AU, Korea, Japan, China, Brazil, India, Argentina and other regional standards
Available DC Connectors
- 5.5*2.1mm
- 5.5*2.5mm
- 4.0*1.7mm
- 3.5*1.35mm
- 2.5*0.7mm
- XLR
- Other customizable options
Applications
Ideal for electric grill ovens, LED strips, audio amplifiers, wireless routers, and audio/video power supplies.
Not waterproof - indoor use only.
Customization Services
We offer comprehensive OEM and ODM services with custom labeling, packaging, and case design options available to meet your specific requirements.
